BMW M3 / Toyota Supra 3.0L B48 11:1 Wossner Piston Kit (Hard Anodised Coating)

This Wössner hard-anodised forged piston kit is listed for Supra, M2 / M3 & M4 3.0 24V Single & Twin Turbo B58 Gen 2 (2019). Catalogue reference: K9559D050-6. Selected bore size: 82.5mm.

Key specifications

• Application: Supra, M2 / M3 & M4 3.0 24V Single & Twin Turbo B58 Gen 2 (2019)
• Manufacturer: BMW; Toyota
• Engine code: B58
• Year range: From 2019
• Catalogue reference: K9559D050-6
• Bore Size: 82.5mm
• Product type: Forged Piston Kits
• Kit Part Number: K9559-6
• Stroke: 94.6mm
• Compression Height: 33.2mm
• OEM Comp Ratio: 11:01
• OEM Rod Length: 148.2mm
• Pin Size: 22mm
• Pin Part Number: WP136-SP
• Clip Part Number: CW22
• Number of Rings: 3
• Cylinders: 6
• Valves Per Cylinder: 4
• Piston number: K9559D050-6

Fitment note: Compare the application, engine code, selected option and listed dimensions with your engine before ordering. Contact TSR Performance if you need a fitment check.
