Performance Dual Valve Spring Kit with Titanium Retainers
Applications: Toyota 3UR-FE V8
| Retainer Qty | 32 |
|---|
| Seat Locator | seat-f4r-ex |
|---|
| Seat Locator Qty | 32 |
|---|
| Kit Spring | spr-ec3025d |
|---|
| Kit Spring Qty | 32 |
|---|
| Safe Rpm Limit | 8000 |
|---|
| Retainer | ret-ec3025/t55 |
|---|
| Rate | 12.80lbs/mm |
|---|
| Coil Bind | 21.80mm |
|---|
| Outer Spring Od | 26.60mm |
|---|
| Outer Spring Id | 19.60mm |
|---|
| Inner Spring Od | 19.40mm |
|---|
| Inner Spring Id | 14.20mm |
|---|
| Seat Pressure | 62lbs @ 37.80mm |
|---|
| Open Pressure | 193lbs @ 10.00mm |
|---|
| Max Lift | 13.90mm |
|---|
- Manufacturer: Supertech Performance
- Manufacturer part number: SPRK-EC3025D-3UR
Please confirm the selected specification and engine application before ordering.
