Performance Dual Valve Spring Kit with Titanium Retainers
Applications: Toyota 2TR-FE
| Retainer Qty | 16 |
|---|
| Seat Locator | seat-3020-2rz |
|---|
| Seat Locator Qty | 16 |
|---|
| Kit Spring | spr-ec3027d |
|---|
| Kit Spring Qty | 16 |
|---|
| Safe Rpm Limit | 8000 |
|---|
| Retainer | ret-ec3020/t55 |
|---|
| Rate | 11.70lbs/mm |
|---|
| Coil Bind | 22.20mm |
|---|
| Outer Spring Od | 26.60mm |
|---|
| Outer Spring Id | 19.60mm |
|---|
| Inner Spring Od | 19.60mm |
|---|
| Inner Spring Id | 14.20mm |
|---|
| Seat Pressure | 85lbs @ 37.00mm |
|---|
| Open Pressure | 203lbs @ 10.00mm |
|---|
| Max Lift | 11.50mm |
|---|
- Manufacturer: Supertech Performance
- Manufacturer part number: SPRK-EC3027D-2TR
Please confirm the selected specification and engine application before ordering.
