Performance Beehive Valve Spring Kit with Titanium Retainers
Applications: Toyota 1GR-FE
| Safe Rpm Limit | 8000 |
|---|
| Kit Spring Qty | 24 |
|---|
| Kit Spring | spr-fm46-be-2 |
|---|
| Outer Spring Od | 27.30mm |
|---|
| Outer Spring Id | 19.10mm |
|---|
| Inner Spring Od | 24.50mm |
|---|
| Inner Spring Id | 16.30mm |
|---|
| Seat Pressure | 92lbs @ 36.40mm |
|---|
| Open Pressure | 220lbs @ 10.00mm |
|---|
| Max Lift | 14.40mm |
|---|
| Coil Bind | 22.80mm |
|---|
| Rate | 13.7lbs/mm |
|---|
| Retainer | ret-a2416-t1 |
|---|
| Retainer Qty | 24 |
|---|
| Seat Locator | use oem seat |
|---|
| Seat Locator Qty | 24 |
|---|
- Manufacturer: Supertech Performance
- Manufacturer part number: SPRK-FM46-1GR-BE1
Please confirm the selected specification and engine application before ordering.
