Performance Beehive Valve Spring Kit with Titanium Retainers
Applications: Subaru FA20; Subaru FA20F (DIT); Toyota FR-S 4U-GSE
| Outer Spring Od | 29.10mm |
|---|
| Kit Spring Qty | 16 |
|---|
| Kit Spring | spr-h1002d-be |
|---|
| Seat Locator Qty | 16 |
|---|
| Seat Locator | seat-h1002d-brz-2 |
|---|
| Retainer Qty | 16 |
|---|
| Retainer | ret-h55be-brz |
|---|
| Rate | 9.70lbs/mm |
|---|
| Coil Bind | 19mm |
|---|
| Max Lift | 13mm |
|---|
| Open Pressure | 170lbs @ 10.00mm |
|---|
| Seat Pressure | 72lbs @ 33.50mm |
|---|
| Inner Spring Id | 23mm |
|---|
| Inner Spring Od | 23mm |
|---|
| Outer Spring Id | 21.30mm |
|---|
| Safe Rpm Limit | 8000 |
|---|
- Manufacturer: Supertech Performance
- Manufacturer part number: SPRK-H1002-BRZ-BE
Please confirm the selected specification and engine application before ordering.
