Supertech Mitsubishi 4G63 Performance Dual Valve Spring Kit with Titanium Retainers SPRK-M1007D
Build your specification using the selectors above. The exact Supertech part number and price update after selection.
| Part number | Seat Pressure |
|---|
| SPRK-M1007D | 92lbs @ 39.60mm |
| SPRK-M1007D-2 | 100lbs @ 39.00mm |
| SPRK-M1007D-3 | 110lbs @ 38.10mm |
Performance Dual Valve Spring Kit with Titanium Retainers
Applications: Mitsubishi 4G63
| Seat Locator | seat-m1007d |
|---|
| Seat Locator Qty | 16 |
|---|
| Kit Spring | spr-m1007d |
|---|
| Kit Spring Qty | 16 |
|---|
| Valve Seals | vs-h6.6e |
|---|
| Valve Seals Qty | 16 |
|---|
| Safe Rpm Limit | 8000 |
|---|
| Retainer Qty | 16 |
|---|
| Retainer | ret-m65/t1 |
|---|
| Rate | 12.50lbs/mm |
|---|
| Outer Spring Od | 28.10mm |
|---|
| Outer Spring Id | 20mm |
|---|
| Inner Spring Od | 20mm |
|---|
| Inner Spring Id | 15.20mm |
|---|
| Seat Pressure | 92lbs @ 39.60mm |
|---|
| Open Pressure | 235lbs @ 11.50mm |
|---|
| Max Lift | 14.90mm |
|---|
| Coil Bind | 24.70mm |
|---|
- Manufacturer: Supertech Performance
- Manufacturer part number: SPRK-M1007D
Please confirm the selected specification and engine application before ordering.
