Performance Single Valve Spring Kit with Titanium Retainers
Applications: Mazda 626; Mazda MX6; Mazda Probe; Mazda Protege
| Kit Spring | spr-tc25s |
|---|
| Kit Spring Qty | 16 |
|---|
| Safe Rpm Limit | 8000 |
|---|
| Inner Spring Od | single |
|---|
| Inner Spring Id | single |
|---|
| Seat Locator Qty | 16 |
|---|
| Seat Locator | use oem seat |
|---|
| Outer Spring Od | 25mm |
|---|
| Outer Spring Id | 18mm |
|---|
| Seat Pressure | 58lbs @ 34.80mm |
|---|
| Open Pressure | 142lbs @ 11.00mm |
|---|
| Max Lift | 13.80mm |
|---|
| Coil Bind | 21mm |
|---|
| Rate | 7.60lbs/mm |
|---|
| Retainer | ret-2500/t1 |
|---|
| Retainer Qty | 16 |
|---|
- Manufacturer: Supertech Performance
- Manufacturer part number: SPRK-MP20S
Please confirm the selected specification and engine application before ordering.
