Performance Beehive Valve Spring Kit with Titanium Retainers
Applications: Ford Duratec 2.0; Ford Duratec 2.3; Ford Duratec 2.5; Mazda MZR 2.0; Mazda MZR 2.3; Mazda MZR 2.5; Mazda MZR Turbo
| Kit Spring | spr-ts1015-be |
|---|
| Kit Spring Qty | 16 |
|---|
| Safe Rpm Limit | 8000 |
|---|
| Seat Locator Qty | 16 |
|---|
| Seat Locator | seat-dur0 |
|---|
| Retainer Qty | 16 |
|---|
| Outer Spring Od | 24mm |
|---|
| Outer Spring Id | 17.20mm |
|---|
| Inner Spring Od | 21mm |
|---|
| Inner Spring Id | 14.20mm |
|---|
| Seat Pressure | 70lbs @ 35.50mm |
|---|
| Open Pressure | 150lbs @ 10.00mm |
|---|
| Max Lift | 12.50mm |
|---|
| Coil Bind | 21.80mm |
|---|
| Rate | 12.70lbs/mm |
|---|
| Retainer | ret-ts5.5/t1f-be |
|---|
- Manufacturer: Supertech Performance
- Manufacturer part number: SPRK-TS-DUR-BE1
Please confirm the selected specification and engine application before ordering.
