Performance Beehive Valve Spring Kit with Titanium Retainers
Applications: Toyota 1JZ-GTE; Toyota 2JZ-GE; Toyota 2JZ-GTE DOHC
| Seat Locator | use oem seat |
|---|
| Seat Locator Qty | 24 |
|---|
| Kit Spring | spr-ts1012-be |
|---|
| Kit Spring Qty | 24 |
|---|
| Safe Rpm Limit | 8000 |
|---|
| Retainer Qty | 24 |
|---|
| Retainer | ret-ts60/t1-be |
|---|
| Rate | 10.40lbs/mm |
|---|
| Outer Spring Od | 27.70mm |
|---|
| Outer Spring Id | 19.70mm |
|---|
| Inner Spring Od | 23.20mm |
|---|
| Inner Spring Id | 15.20mm |
|---|
| Seat Pressure | 82lbs @ 33.60mm |
|---|
| Open Pressure | 196lbs @ 11.00mm |
|---|
| Max Lift | 11.70mm |
|---|
| Coil Bind | 21.80mm |
|---|
- Manufacturer: Supertech Performance
- Manufacturer part number: SPRK-TS1012-BE
Please confirm the selected specification and engine application before ordering.
