Performance Single Valve Spring Kit with Titanium Retainers
Applications: Toyota 1ZZ-FE; Toyota 2AZ-FE
| Seat Locator Qty | 16 |
|---|
| Kit Spring | spr-ts1015-si |
|---|
| Kit Spring Qty | 16 |
|---|
| Safe Rpm Limit | 8000 |
|---|
| Inner Spring Od | single |
|---|
| Inner Spring Id | single |
|---|
| Seat Locator | seat-ts/tc |
|---|
| Retainer Qty | 16 |
|---|
| Outer Spring Od | 27.50mm |
|---|
| Outer Spring Id | 20mm |
|---|
| Seat Pressure | 58lbs @ 34.00mm |
|---|
| Open Pressure | 157lbs @ 11.00mm |
|---|
| Max Lift | 12.50mm |
|---|
| Coil Bind | 20.70mm |
|---|
| Rate | 9.60lbs/mm |
|---|
| Retainer | ret-ts5.5/tc-s |
|---|
- Manufacturer: Supertech Performance
- Manufacturer part number: SPRK-TS2081-TC
Please confirm the selected specification and engine application before ordering.
