Wössner Piston Kit for RS3 & TTRS 2.5L 20V Turbo 5cyl TFSI 82.5mm – K9523DA
Wössner Piston Kit for RS3 & TTRS 2.5L 20V Turbo 5cyl TFSI 82.5mm – K9523DA

  • Guaranteed Fitment

    Always the correct part

  • In-House Experts

    We know our products

  • Added Value

    Mounting, Balancing

  • Wordwide Delivery

    Free shipping on all order

Wössner Forged Piston Kit for RS3 & TTRS 2.5L 20V Turbo 5cyl TFSI – 82.5mm – K9523DA

(No reviews) Write a Review
£770.56
SKU: WOS-K9523DA
Adding to cart… The item has been added
Description

This Wössner forged piston kit is listed for RS3 & TTRS 2.5L 20V Turbo 5cyl TFSI. Catalogue reference: K9523DA. Selected bore size: 82.5mm.

Key specifications

  • Application: RS3 & TTRS 2.5L 20V Turbo 5cyl TFSI
  • Manufacturer: Audi
  • Engine code: DAZA
  • Year range: 2016–2019
  • Catalogue reference: K9523DA
  • Bore Size: 82.5mm
  • Product type: Forged Piston Kits
  • Kit Part Number: K9523
  • Stroke: 92.8mm
  • Compression Height: 29.5mm
  • OEM Comp Ratio: 10:01
  • OEM Rod Length: 144mm
  • Suits Wossner Con Rod: G0331-5
  • Pin Size: 23mm
  • Pin Part Number: WP082
  • Clip Part Number: CW23
  • Number of Rings: 3
  • Cylinders: 5
  • Valves Per Cylinder: 4
  • Con Rod Length Centre-to-centre: 144mm
  • Drawing number: 17019
  • Piston number: K9523DA

Fitment note: Compare the application, engine code, selected option and listed dimensions with your engine before ordering. Contact TSR Performance if you need a fitment check.
