Performance Beehive Valve Spring Kit with Titanium Retainers
Applications: Ford FXR6; Ford FXR6 BARRA
| Safe Rpm Limit | 8000 |
|---|
| Kit Spring Qty | 24 |
|---|
| Outer Spring Od | 26.40mm |
|---|
| Outer Spring Id | 19.50mm |
|---|
| Inner Spring Od | 23.60mm |
|---|
| Inner Spring Id | 16.00mm |
|---|
| Seat Pressure | 83lbs @ 39.3mm |
|---|
| Open Pressure | 167lbs @ 11.00mm |
|---|
| Max Lift | 11.40mm |
|---|
| Coil Bind | 23mm |
|---|
| Rate | 8.00lbs/mm |
|---|
| Retainer | ret-fxr6-t1 |
|---|
| Retainer Qty | 24 |
|---|
| Seat Locator | use oem seat |
|---|
| Seat Locator Qty | 24 |
|---|
| Kit Spring | spr-fxr6-be1 |
|---|
- Manufacturer: Supertech Performance
- Manufacturer part number: SPRK-FXR6-BE1
Please confirm the selected specification and engine application before ordering.
