Performance Single Valve Spring Kit with Titanium Retainers
Applications: Nissan TB48
| Kit Spring Qty | 24 |
|---|
| Spring Shim | seat-tb1020d |
|---|
| Spring Shim Qty | 24 |
|---|
| Safe Rpm Limit | 8000 |
|---|
| Inner Spring Od | single |
|---|
| Inner Spring Id | single |
|---|
| Seat Locator | seat-tb1020d |
|---|
| Kit Spring | spr-h1021s |
|---|
| Seat Locator Qty | 24 |
|---|
| Retainer Qty | 24 |
|---|
| Outer Spring Od | 30mm |
|---|
| Outer Spring Id | 21.80mm |
|---|
| Seat Pressure | 77lbs @ 39.00mm |
|---|
| Open Pressure | 167lbs @ 10.00mm |
|---|
| Max Lift | 17mm |
|---|
| Coil Bind | 22mm |
|---|
| Rate | 9.30lbs/mm |
|---|
| Retainer | ret-h60/t1 |
|---|
- Manufacturer: Supertech Performance
- Manufacturer part number: SPRK-H1021S-TB48
Please confirm the selected specification and engine application before ordering.
