Performance Dual Valve Spring Kit with Titanium Retainers
Applications: Mini R53
| Retainer Qty | 16 |
|---|
| Seat Locator | seat-mc1015d |
|---|
| Seat Locator Qty | 16 |
|---|
| Kit Spring | spr-ts1015 |
|---|
| Kit Spring Qty | 16 |
|---|
| Safe Rpm Limit | 8000 |
|---|
| Retainer | ret-ts60ma2 |
|---|
| Rate | 12.10lbs/mm |
|---|
| Coil Bind | 20.70mm |
|---|
| Outer Spring Od | 27.50mm |
|---|
| Outer Spring Id | 20mm |
|---|
| Inner Spring Od | 20mm |
|---|
| Inner Spring Id | 15.20mm |
|---|
| Seat Pressure | 76lbs @ 34.80mm |
|---|
| Open Pressure | 198lbs @ 10.00mm |
|---|
| Max Lift | 14mm |
|---|
- Manufacturer: Supertech Performance
- Manufacturer part number: SPRK-TS1015-MC
Please confirm the selected specification and engine application before ordering.
