Performance Beehive Valve Spring Kit with Titanium Retainers
Applications: BMW S54B32
| Retainer Qty | 24 |
|---|
| Seat Locator | seat-bms54-be |
|---|
| Seat Locator Qty | 24 |
|---|
| Kit Spring | spr-hm1007be |
|---|
| Kit Spring Qty | 24 |
|---|
| Safe Rpm Limit | 8000 |
|---|
| Retainer | ret-bm2521/t1-be |
|---|
| Rate | 12.80lbs/mm |
|---|
| Coil Bind | 22.80mm |
|---|
| Outer Spring Od | 28mm |
|---|
| Outer Spring Id | 18.80mm |
|---|
| Inner Spring Od | 24.20mm |
|---|
| Inner Spring Id | 14.50mm |
|---|
| Seat Pressure | 76lbs @ 36.00mm |
|---|
| Open Pressure | 204lbs @ 10.00mm |
|---|
| Max Lift | 14mm |
|---|
- Manufacturer: Supertech Performance
- Manufacturer part number: SPRK-HM1007BE-S54
Please confirm the selected specification and engine application before ordering.
